A globe valve is a type of mechanical device used to control the flow of fluid within a pipeline. It features a spherical body with an internal baffle and a movable disk or plug that regulates the flow by either obstructing or allowing passage through the valve. The design allows for precise control of fluid flow rates and is commonly employed in various industries such as oil and gas, water treatment, and manufacturing. Globe valves are known for their reliability, versatility, and ease of maintenance, making them a popular choice for applications requiring accurate flow control.
- Material Composition:
- Cast iron body
- Rubber seal
- Dimensions:
- Length: 200 mm
- Nominal Diameter: DN40 mm
- Weight: 2.6 kg
- Pressure Rating:
- Operating Pressure: 1.2 MPa
- Burst Pressure: 140 MPa
- Temperature Range for water:
- 5 C – 110 C
